To locate the best VPC cable or PCB adapter solution for your PXI test instrument, to use VPC's Cable Solution Selector online tool.Search by PXI module part #, model #, or type to locate a solution for your instrument.

VPC has a large number of pre-configured cable assembly solutions to meet a variety of interface needs.

  • TriPaddle
  • QuadraPaddle
  • Mini/Micro Coax
  • Other

VPC cable assembly solutions beginning with the digits "540", use part number logic that incorporate length as follows-

Example: p/n 540014010X01,

if "X" = length =

  • 1 20" [508 mm]
  • 2 36" [914 mm]
  • 6 48" [1219 mm]
  • 9 60" [1524 mm]
  • 5 72" [1829 mm]

The following links are for cable assembly solution drawings. If you are in need of further assistance, please contact us.

TriPaddle

Part No.DescriptionCompatible With
540003010X03TriPaddle to 96-Pin FML SCSIPickering 40-793-701 40-531-022 40-532-022 40-280-121
540005010X05TriPaddle to 200-Pin ML LFH w/ 4-40 JackscrewsPickering 40-533B-031 40-533B-021 40-615A-018 40-610A-007 40-680-001 40-533B-032
540007010X03TriPaddle to 68-Pin ML SCSIPickering 40-290-021
540010020X01TriPaddle to 9-Pin FML D-SubKeysight 34945A
540014010X01TriPaddle to 25-Pin FML D-SubPickering 40-375001 40-650-011 41-650-001/ 001-S1 NI PXIe-4140 PXIe-4147
540016010X01TriPaddle to 37-Pin FML D-SubNI PXI-6521 PXI-6230 PXI-6233 PXI-6238 Pickering 40-480-221 40-540-001 40-548-001 40-650-002 40-295-021-3/24 40-298-034
540016020X03TriPaddle to 37-Pin FML D-SubPickering 40-137-001
540016050X01TriPaddle to 5A 37-Pin FML D-SubNI PXI-2564
540016070X01TriPaddle to 37-Pin FML D-Sub and 4 POS Micro Fit ConnNI PXIe-2727
540016090X01TriPaddle to 37-pin FML D-Sub and 4 POS Micro Fit ConnNI PXI-2720
540018010X01TriPaddle to 50-Pin FML D-SubPickering 40-156-001
540029010X01TriPaddle to 2 x 16-Pin FML Mini Combicon HeadersNI PXI-2565
540034010X03TriPaddle to 78-Pin FML D-SubPickering 40-500/501/ 506/507-001 40-518A/519B-002 40-525A-001/002 40-527A-001 40-576/577-001 40-582A/585A-001 NI PXI-2567
540037010X11TriPaddle & Mini Coax to 3 x BNC, 1 x SMB, 1 x 9-Pin DINPXI-5114
540039010X11TriPaddle & Mini Power to 4 x Ban Plug, 9-Pin DIN, 600VPXI-4070
540039030X11TriPaddle & Mini Power to 4 x Ban Plug, 9-Pin DIN, 1000VNI PXI-4071
540041010X01TriPaddle to 2 x 9-Pin FML D-SubsNI PXI-8431/2 PXI-8433/2 PXI-8516
540041020X01TriPaddle to 2 x 9-Pin FML D-Subs f/ High Speed CANNI PXI-8512/2
540043010X01TriPaddle to 4 x RJ-50NI PXI-8430/4 PXI-8431/4 PXI-8432/4 PXI-8433/4
540046030X03Tri-Paddle to 62-Pin FML D-SubNI PXI-2566
540054010X01TriPaddle to 2 x 20-Pin FML Power ConnPickering 40-160-002 40-160-003
540054040X01TriPaddle to 2 x 20-Pin FML Power ConnPickering 40-660A-002
540078010X11TriPaddle & Mini Power to 1 x 7-Pin Din, 4 x Banana Pl
540080010X302 x Mods, TriPaddle to 68-Pin VHDCI & Mini Coax to 3 x FML SMB
540083020X03TriPaddle to 68-Pin FML SCSINI PXI-6704
540096010X11TriPaddle & Mini Coax to 3 x BNC, 2 x SMB, 1 x 9-Pin DINNI PXI-5122 PXI-5922
540103010X302 x Mods, TriPaddle to 68-Pin ML VHDCI & Mini Coax to 4 x SMB
540105010X05TriPaddle to 200-Pin ML LFH w/ M3 Jackscrews
540105020X05TriPaddle to 200-Pin ML LFH w/ M3 JackscrewsNI PXI-2569 PXIe-2569 PXI-2570 PXI-2571
540105040X05TriPaddle to 200-Pin ML LFH w/ M3 JackscrewsNI PXIe-2575
540111020X03TriPaddle to 2 x 50- Pin D-SubKeysight 34938A
540111030X03TriPaddle to 2 x 50-Pin FML D-SubKeysight 34937A
540118050X03TriPaddle to 68-Pin ML SCSI
540119030X01TriPaddle to 37-Pin FML D-Sub 1000VPickering 40-331A-003
540120030X01TriPaddle to 68-Pin Male VHDCIPXIe-8431/8
540127010X01TriPaddle to 2 x 9-Pin FML DSUBNI PXI-8430/2 PXI-8432/2
540145010X01TriPaddle to 20-Pin Power ConnPickering 40-160-001 NI PXI-2585/6
540152020X05TriPaddle to 200-Pin ML LFH 4-40 JackscrewsPickering 40-540-021 40-534A-021-S 40-534A-022 40-533B-022
540162010X01TriPaddle to 6 & 2 Pos Mini-Combicon ConnNI PXI-4110 PXI-4130
540170010X432 x Mods, TriPaddle to 1 x 68-Pin ML VHDCI & 20/26 GHz to 4 x SMA, 2 x SMB
540191020X01TriPaddle to 24-Pin NI GPIBNI GPIB
540212020X03CBA PXI SIG 68 PN VHDCI ML
540214010X01TriPaddle to 1 x 9-Pin FML, 1 x 15-Pin FML D-SUBs
540260010X00TriPaddle 36" 50P HRWN FLY LD
540278010X59TriPaddle to 2 x 9-Pin FML D-SUB, 2 x SMBNI PXI-8513
540281010X01TriPaddle to NI TB-4300BNI PXIe-4300
540285010X03TriPaddle to 2 x ML Infiniband, 1 x FML SMBNI PXIe-4497
540295010X01TriPaddle to 10-Pos Combicon, 4-Pos OmnimateNI PXIe-4112 PXIe-4113
540307020X05TriPaddle to 3 x 68-Pin ML Offset VHDCINI PXI-6365
540325010X01TriPaddle to NI TB-4322NI PXIe-4322
540352010X01TriPaddle to 6 x 9-Pin FML D-Sub
540355010X01TriPaddle CBA RCV 20" TB-4300
540361010X11TriPaddle/ Mini-Power to Ban Plug x 4, 7-Pin ML DINKeysight M9182A
541123199TriPaddle to NI TB-2627, 36"NI PXI-2527
541122953TriPaddle to 4 X BJ, 1 x HDI NI TB-2627, 20"NI PXI-2527
541123200TriPaddle to 4 X BJ, 1 x HDI NI TB-2627, 36"NI PXI-2527

QuadraPaddle

Part No.DescriptionCompatible With
540009010X40QuadraPaddle to 100-Pin ML SCSINI PXI-6624
540009040X40QuadraPaddle to 100-Pin ML SCSINI PXI-6508/9 PXI-6511 PXI-6513/14/15 PXI-6528/9 PXI-6624
540025010X40QuadraPaddle to 160-Pin LFH ConnNI PXI-2576
540030010X40QuadraPaddle to 8-Pin RJ45 Plug
540031020X40QuadraPaddle to 2 x 68-Pin ML VHDCINI PXIe-6363 PXIe-6363
540034010X40QuadraPaddle to 78-Pin FML D-SubKeysight M9187A M9130A Pickering 40-131-101/201 40-132-101/201 40-136-112/211/212 40-137-101/201 40-411/412/413-001 NI PXI-2567
540034010X29QuadraPaddle to 2 x 78-Pin FML D-SubNI PXI-2567
540034050X40QuadraPaddle to 78-Pin FML D-SubPickering 40-739-001/002-006 42-739-001/002-006
540069010X29QuadraPaddle to 160-Pin DIN FML ConnPickering 40-139-101
540069010X40QuadraPaddle to 160-Pin DIN FML ConnNI PXI-2520/1/2/3 PXIe-2524/5/6
540069040X40QuadraPaddle to 160-Pin DIN FML ConnPickering 40-139-101 40-575A-001
540069110X40QuadraPaddle to 160-Pin DINNI PXIe-2525
540069120X40QuadraPaddle to 160-Pin FML DIN, Twisted PairNI PXIe-2737
540072010X40QuadraPaddle to 2 x 68-Pin ML VHDCI
540072020X40QuadraPaddle to 2 x 68-Pin VHDCINI PXI-6723
540105080X05QuadraPaddle to 200-Pin ML LFH M3</
