FFC FPC Extension Board PCB Extend Connector 20 Pin 0.5mm Pitch Single Side 5pcs

ID:1213603

About this item

  • FPC/FFC Extension Board often found in high density electronic applications like those small electrical equipment. Widely used for laptops, DVD player, LCD monitors and other DIY projects, etc.
  • Single Sided PCB Support; 20 Pins; 0.5mm Pitch; Overall Size: 21x20x3 mm/ 0.83x0.79x0.12 inch(L*W*T); In the package of: 5 x FPC/FFC Board.
  • Converter board for PCB connection. The board can be used with the ultra thin flat flexible ribbon cable, can save much space for your connecting.
  • Steps of installations: 1. Flip-up the black interface ; 2.Insert into your flat cable(here is not included); 3.Test to finish.
  • The PCB board is just a convert board. All size above is measured by manual, please allow +/-0.1 inch error.

Specification

SpecificationDetails
SKUa22011100ux0281
Product typePCB Support
Pin count20 Pins
Fpc connector pitch0.5mm
Overall size21x20x3 mm/ 0.83x0.79x0.12 inch(L*W*T)
In the package of5 x FPC/FFC Board
Product Description

What is this?

FPC/FFC Extension Board often found in high density electronic applications like those small electrical equipment. Widely used for laptops, DVD player, LCD monitors and other DIY projects, etc.

What will I get?

The FPC/FFC board we provide here, is in the size of:

Board Type
