Trek 20/20C-HS +/-20 kV/20 mA-100 mA High Voltage Amplifier & Power Supply with All Cables, Refurbished

Check Trek website for 20/20C-HS specifications. This is the current model.

Product Description

With original 3 m long high voltage cable, 2 m grounding cable, two BNC cable, power cord.

Provide Skype training for free.

Note: for this unit, we only accept bank transfer payment, or net 30 PO from university. Please do NOT pay with credit card.

Shipping cost is only for US domestic customers. International customers need to pay additional shipping cost and end user declaration.

Trek is a registered trademark of Advanced Energy Industries, Inc.

The product is used surplus. PolyK is not a

Specifications

• Output Voltage: 0 to ±20 kV DC or peak AC
• Output Current: 0 to ±20 mA DC or 100 mA peak AC for 4 ms (cannot exceed 20 mA RMS)
• Slew Rate: Greater than 800 V/µs
• Large Signal Bandwidth: DC to greater than 6.5 kHz (3dB)
• Gain: 2000 V/V Fixed
