fr4 semiflex pcb code

Polyimide Flexible Rigid PCB

Product Details

Place of Origin

China

Brand Name

OEM Customized

Certification

ISO/RoHS/TS16949

Model Number

HKCC2211YH162

Payment & Shipping Terms

Minimum Order Quantity

2pcs

Price

USD10-USD100

Packaging Details

Inner packing :bubble bag Outer packing :Standard carton box

Delivery Time

20 workdays

Payment Terms

T/T

Supply Ability

5000PCS/WEEK

Product Description

Highlight: Polyimide Flexible Rigid PCB, Multipurpose Flexible Rigid PCB, Punched Flexible Circuit Assembly

Base Material

Polyimide Material Thickness(mm):0.1-0.5mm Board Outline Tolerance:±0.25mm Mini Hole Size(mechanical):0.15mmPTH Mini PTH Hole Ring:0.45mm Trace Width Tolerance:±0.03mm,W±30% Hole Size Tolerance:±0.05mm Contours:Scored, Routed, Punched

Base Material:Polyimide Material Thickness(mm):0.1-0.5mm Board Outline Tolerance:±0.25mm Mini Hole Size(mechanical):0.15mmPTH Mini PTH Hole Ring:0.45mm Trace Width Tolerance:±0.03mm,W±30% Hole Size Tolerance:±0.05mm Contours:Scored, Routed, Punched

Flexible Rigid-Flex Circuits Technology Technical Engineering Guide Rigid-Flex Pcb

Files and requirment for PCBA quotation

• A BOM (Bill of Materials) with reference designators: component description, manufacturer’s name and part number.
• PCB Gerber files.
• A PCB fabrication drawing and PCBA assembly drawing.
• Test procedures.
• Any mechanical restrictions such as assembly height requirements

PRODUCT PARAMETERS

PCB board manufacture and PCBA service:

• PCB board made, circuit board parts purchased by us
• Electronic testing circuit board or PCBA
• Fast delivery,anti-static package
• RoHC Directive-compliant, lead-free
• One stop service from PCB design,PCB layout,PCB manufacture,components purchasing
• PCB assembly,test,packing and PCB delivery
• Electronic manufacturing service
