Name: ISOLA 370HR PCB
Material: isola 370hr HIGH TG PCB
Df (dissipation factor): 0.021
Dk (dielectric constant): 4.04
Glass transition temperature: TG180℃
Td: 340℃
Number of Layers: 6 layers
Board thickness: 1.0mm
Surface technology: Immersion gold
Copper thickness: 1OZ
Minimum line width/line spacing: 4mil/4mil
kingford designed 370HR laminate and prepreg made with a patented high performance 180°C Tg FR-4 multifunctional epoxy system designed for multilayer printed wiring boards requiring maximum thermal performance and reliability (PWB) applications. We manufacture 370HR laminates and prepregs using premium E-glass fabric for superior conductive anode filament (CAF) resistance. 370HR offers excellent thermal performance with a low coefficient of thermal expansion (CTE) and mechanical, chemical and moisture resistance properties that equal or exceed those of traditional FR-4 materials.
The 370HR is used in thousands of PWB designs and has proven to be best in class in thermal reliability, CAF performance, ease of processing and performance in sequential lamination designs.
