Luminus Horticulture LEDs

Luminus Horticulture LEDs offer industry leading performance in term of PPF (Photosynthetic Photon Flux) and PPF/W metrics and come in a variety of package types ranging from mid-power to high power LEDs

Applications

  • Top lighting, inter lighting and multi-layer cultivation.
  • Urban farming
  • Agriculture lighting and algae growth lights

Features

  • Extensive range of LED packages with excellent PPF and PPF/W values
  • High-power 3535 series offered in 90 and/or 130° viewing angle at 50% Iv
  • Low Thermal Resistance
  • Built-in ESD Protection
  • RoHS and REACh compliant

Overview

  • 3535 packaging solution covering wavelengths from UV (365nm) to Far Red (730nm) for high power applications
  • Plant-specific spectrums in COB package
  • High PPF efficacy mid-power LEDs for cost-constrained horticulture fixtures

SST Series Selector Guide

ProductColorPackageMax Drive CurrentOptical OutputStatus
SST-10-UV365 nmSMT 3.45 mm x 3.45 mm1.0 A0.7 W - 0.9 WActive
385 nm0.9 W - 1.2 W
395 nm0.9 W - 1.2 W
405 nm0.8 W - 1.0 W
SST-10-BBlue (452.5 nm)SMT 3.45 mm x 3.45 mm1.5 A590 - 750 mW (0.35 A)Active
SST-20-BBlue (450 nm)SMT 3.45 mm x 3.45 mm3.0 A630 - 830 mW (0.35 A)Active
SST-10-SBSky Blue (470 nm)SMT 3.45 mm x 3.45 mm1.5 A470 - 590 mW (0.35 A)Active
SST-10-GGreen (527 nm)SMT 3.45 mm x 3.45 mm1.5 A230 - 390 mW (0.35 A)Active
SST-10-RRed (621 nm)SMT 3.45 mm x 3.45 mm1.5 A270 - 430 mW (0.35 A)Active
SST-10-DRDeep Red (660 nm)SMT 3.45 mm x 3.45 mm1.5 A270 - 430 mW (0.35 A)Active
SST-20-DR Gen 2Deep Red (660 nm)SMT 3.45 mm x 3.45 mm2.0 A870 - 1070 mW (0.70 A)Active
SST-20-DR Gen 3Deep Red (660 nm)SMT 3.45 mm x 3.45 mm2.0 A990 - 1110 mW (0.70 A)Active
SST-10-FR730 nmSMT 3.45 mm x 3.45 mm1.5 A (CW)1.27 WActive
SFT-12R-WES-A (3535 Package)White 5000 - 6500 K CRI 70SMT 3.45 mm x 3.45 mm3 A841 - 938 lm (3 A)Active
SFT-12R-WES-F (5050 Package)White 5000 - 6500 K CRI 70SMT 5.0 mm x 5.0 mm3 A841 - 938 lm (3 A)Active
SFT-25R-WES-AWhite 5000 - 6500 K CRI 70SMT 3.45 mm x 3.45 mm7.5 A1,934 - 2,156 lm (7.5 A)Active
SST-10-UV LEDs
Features
  • High Power UV LED with Peak Wavelengths between 365-405nm
  • Industry standard 3.5mmx3.5mm package
  • 130° viewing angle at 50% Iv
  • Low Thermal Resistance - 3.4 C/W
  • Built-in ESD Protection
Applications
  • Horticulture
  • Curing
  • Adhesives
  • Inks
  • Plastic Products
