Industrial Control PCBA

Industrial Control PCBAs are the essential components that drive automation in various industries. These specialized circuit boards are designed to control and monitor industrial processes, ensuring precise and efficient operations.

From manufacturing plants to energy infrastructure, industrial control PCBAs are responsible for tasks such as motor control, temperature regulation, and data acquisition. By integrating advanced technologies like microcontrollers, sensors, and communication protocols, these PCBAs enable automation and optimize industrial processes.

Industrial Control PCBA Details

Specification	Details
Layers	1-40+ layers
Assembly Type	Through-Hole (THT), Surface Mount (SMT), Mixed (THT+SMT)
Minimum Component Size	01005 or 0201 (Imperial) / 0402 or 0603 (Metric)
Maximum Component Size	2.0 in x 2.0 in x 0.4 in (50 mm x 50 mm x 10 mm)
Component Package Types	BGA, QFN, QFP, SOIC, SOP, SSOP, TSSOP, PLCC, DIP, etc.
Minimum Pad Pitch	0.5 mm (20 mil) for QFP, QFN, 0.8 mm (32 mil) for BGA
Minimum Trace Width	0.10 mm (4 mil)
Minimum Trace Spacing	0.10 mm (4 mil)
Minimum Drill Size	0.15 mm (6 mil)
Maximum Board Size	18 in x 24 in (457 mm x 610 mm)
Maximum Board Thickness	0.062 in (1.6 mm) to 0.125 in (3.2 mm)
Board Material	FR-4, High-Tg FR-4, Aluminum, High Frequency, Flexible(FPC), Rigid-Flex, Rogers, etc.
Surface Finish	HASL, Immersion Gold, Gold Finger, OSP, Immersion Silver, etc.
Solder Paste Type	Leaded or Lead-Free
Assembly Process	Reflow Soldering, Wave Soldering, Hand Soldering
Inspection Methods	Automated Optical Inspection (AOI), X-ray, Visual Inspection
Testing Methods	In-Circuit Test (ICT), Functional Test (FCT), Flying probe test
Design for Manufacturing (DFM)	DFM Analysis and Feedback
Turnaround Time	Prototype: 24 hours to 7 days, Production: 10 days to 4 weeks
PCB Assembly Standards	ISO9001:2015;ISO13485:2016;ROHS,UL 94v0, IPC-600G classll and IPC-6012B classll standard
