20kw lithium battery bank
20kw lithium battery bank
Product Description
Key Specifications
Battery Type: LiFePO4 (3500 Cycles*)
Nominal Voltage: 432V
Nominal Capacity: 100AH/200AH
Charge and Discharge Port: Same Port
Overcharge Recovery Voltage: 465.75V
Over Temp. Protection: Charge: 0~55℃; Discharge: -10~65℃
LCD Display: Master control LCD display
Communication Function: CAN & RS485
Dimension: 1380mm*1080mm*600mm (TBD)/1500mm*1800mm*750mm (TDB)
Detailed Technical Parameters
Parameter
432V 100Ah
432V 200Ah
Battery Type
LiFePO4 (3500 Cycles*)
LiFePO4 (3500 Cycles*)
Nominal Voltage
432V
432V
Nominal Capacity
100Ah
200Ah
Configuration
135S1P
135S1P
Load Power
43.2KW Rated
80KW;Max. 86KW
Charge Current
Continuous: 80A Max.: 100A
Continuous: 100A Max.: 200A
Discharge Current
Max. Continuous: 100A
Max. Continuous: 200A
Charge and Discharge Port
Same Port
Same Port
Over Charge Voltage
492.75V (Single cell: 3.65V)
492.75V (Single cell: 3.65V)
Over Charge Delay
100ms 1000ms
100ms 1000ms
Overcharge Recovery Voltage
465.75V
465.75V
Over Discharge Voltage
337.5V (Single cell: 2.5V)
337.5V (Single cell: 2.5V)
Over Discharge Delay
200ms 2000ms
200ms 2000ms
Overdischarge Recovery
Charge recovery
Charge recovery
Over Current
150A
250A
Over Current Delay
200ms 2000ms
200ms 2000ms
Over Current Recovery
Disconnect Load
Disconnect Load
Shortcircuit Protection
Disconnect Load
Disconnect Load
Over Temp. Protection
Charge: 0~55℃; Discharge: -10~65℃
Charge: 0~55℃; Discharge: -10~65℃
Balance Function
Passive equalization
Passive equalization
LCD Display
Master control LCD display
Master control LCD display
Communication Function
CAN & RS485
CAN & RS485
Pre-charge & Pre-discharge Function
Pre-charge current: 20A Pre-discharge current: 20A Precharge Resistor:10Ω 200W
Pre-charge current: 40A Pre-discharge current: 40A Precharge Resistor:10Ω 400W
Dimension
1380mm*1080mm*600mm (TBD)
1500mm*1800mm*750mm (TDB)
Remark
Charging and discharging aerial plug: (FN08-200-001SS/left negative and right positive)*22 Relay: HFZ16V-100P/900-24-SHSA1.5E-1*3 Circuit breaker: DM6Z -125S/3310 100A DC 500V/DV24*1 Fuse: FWP-125A/700VDC/AC*1 RX24-200W*1
Charging and discharging aerial plug: (FN 08-200-001SS/left positive and right negative)*22 Relay: HFZ16V-200P/900-24-SHSA1.5E-1*3 Circuit breaker: DM6Z -125S/3310 200A DC 500V/DV24*1 Fuse: FWP-250A/700VDC/AC*1 RX24-400W*1
