Isolated PCB Mount DC DC Converters

PH-A Series - 50W to 1200W - Single Output

New Recommended

• Quarter, Half & Full Brick Sizes
• 200-425 Vdc Input
• 3.3, 5, 12, 24, 28, 48 Vdc Outputs
• 3000 Vac Isolation
• -40 to 100 °C Baseplate Temperature
• IEC/EN62477-1 OVCIII (300-600W)
• Parallel Operation (1200W)

CN-B Series - 50W to 300W - Single Output

New Recommended

• Standard Quarter and Half Brick Footprint
• 43-160Vdc Input
• 5, 12, 13.8, 24, 48 Vdc Outputs
• 3000 Vac Isolation
• Current share function (CN200B110 and CN300B110 only)
• IEC61373 Shock & Vibration
• Five year warranty

PYH Series - 200W - Single Output

New Recommended

• 3000V Input to Output Isolation
• Potted Plastic Case
• Wide Range Input 12:1 (14 - 160VDC)
• Industry Standard Package Sizes
• IEC62368-1, CE and UKCA Mark
• Suitable for Railway and Industrial Applications

GQA Series - 120W - Single Output

Recommended

• Standard Quarter Brick Footprint
• 9-36 Vdc, 18-36 Vdc Inputs
• 5, 12, 15, 24, 28, 48 Vdc Outputs
• 1500 Vdc up to 3000 Vdc Isolation
• -40 to 105°C Baseplate temperature
• Open Frame or Encapsulated Construction
• Flanged or Non-flanged Baseplate

HQA Series - 85W to 120W - Single Output

Recommended

• Standard Quarter Brick Footprint
• 9-40 Vdc, 18-40 Vdc Inputs
• 3.3, 5, 12, 15, 24, 28, 48 Vdc Outputs
• 2250 Vdc Isolation
• -55 to 115°C Baseplate temperature
• MIL-STD-461; 1275; 704; DO-160
• No Optocouplers used

PYQ Series - 30W to 75W - Single Output

New Recommended

• 3000V Input to Output Isolation
• Potted Plastic Case
• Wide Range Input 12:1 (14 - 160VDC) and 8:1 (9 - 75VDC)
• Quarter-Brick Footprint
• IEC62368-1, CE and UKCA Mark
• Suitable for Railway and Industrial Applications

CCG Series - 1.3W to 30W - Single Output / Multiple Output

New Recommended

• Space Saving Package Sizes
• 4.5-18V, 9-36 Vdc or 18-76 Vdc Inputs
• 3.3, 5, 12, 15, 24, 30, ±12, ±15 Vdc Outputs
• 1500 Vdc Isolation
• -40 up to 110 °C Case Temperature
• Six-Sided Shielding (CCG15-30)
• Through-hole and SMT terminations (CCG1R5-10)

PXD-M Series - 30W - Single Output / Multiple Output

New Recommended

• Industry Standard 2" x 1" Footprint
• 9-36, 18-75 Vdc Inputs
• 5, 12, 15, 24, ±5, ±12, ±15 Vdc Outputs
• 5000kVac Input to Output Isolation
• -40 to +105 °C Case Temperature
• Medical and Industrial Safety Certifications
• Low No Load Power Consumption

PXG-M Series - 15W to 20W - Single Output / Multiple Output

New Recommended

• Industry Standard 1.6" x 1" Footprint
• 9-36, 18-75 Vdc Inputs
• 5, 12, 15, 24, ±5, ±12, ±15 Vdc Outputs
• 5000kVac Input to Output Isolation
• -40 to +105 °C Case Temperature
• Medical and Industrial Safety Certifications
• Low No Load Power Consumption

PYD Series - 20W - Single Output / Multiple Output

New Recommended

• 3000V Input to Output Isolation
• Potted Plastic Case
• Wide Range Input 18:1 (8.5 - 160VDC)
• Industry Standard Package Sizes
• IEC62368-1, CE and UKCA Mark
• Suitable for Railway and Industrial Applications

iQK Series - 1008W - Single Output

• Standard Quarter Brick Footprint
• 48-56 Vdc Input
• 11.2 Vdc Output
• 707 Vdc Isolation
• Baseplate Cooled
• 97% Typical Efficiency
• Droop Load Share Option

iQG Series - 300W to 504W - Single Output

• Standard Quarter Brick Footprint
• 36-76 Vdc Inputs
• 9.6, 12 Vdc Outputs
• 1500 Vdc Isolation
• Baseplate Cooled
• 94.5% Typical Efficiency
• Droop Load Share Option

iQL Series - 72W to 308W - Single Output

• Standard Quarter Brick Footprint
• 18-36 Vdc, 36-76 Vdc Inputs
• 1.2, 2.5, 3.3, 5, 12, 28 Vdc Outputs
• 1500 Vdc Isolation
• Open frame or Baseplate options
• Up to 94% Efficiency

iEH Series - 300W - Single Output

• Standard Eighth Brick Footprint
• 36-75 Vdc Input
• 10.8, 11.6 and 12 Vdc Outputs
• 2250 Vdc Isolation
• Digital adaptive control
• Constant Switching Frequency

CN-A Series - 30W to 200W - Single Output

• Standard Quarter / Half Brick Footprint
• 14.4-36 Vdc, 60-160 Vdc Inputs
• 5, 12, 15, 24 Vdc Outputs
• 3000 Vac Isolation
• -40 to 100 °C Baseplate Temperature
• IEC61373 Shock & Vibration
• Five year warranty

PXD Series - 10W to 60W - Single Output / Multiple Output

• Industry Standard 2" x 1" Footprint
• 9-18, 9-36, 18-36, 18-75, 36-75 Vdc Inputs
• 3.3, 5, 12, 15, 24, 48, ±5, ±12, ±15, ±24 Vdc Outputs
• 1600 Vdc Isolation
• -40 to 105 °C Case Temperature
• Six-sided Shielding
• EN61000-4 Immunity

PXF Series - 40W to 60W - Single Output / Multiple Output

• Industry Standard 2" x 2" Footprint
• 9-18, 9-36, 18-36, 18-75 Vdc Inputs
• Single, Dual and Triple Outputs
• 1600 Vdc Isolation
• -40 to 100 °C Case Temperature
• Six-sided Shielding
• EN61000-4 Immunity

CC-E Series - 1.3W to 10W - Single Output / Multiple Output

• Compact Footprint / Low Profile
• 5, 12, 24 and 48 Vdc Nominal Inputs
• 3.3, 5, 12, 15, ±12, ±15 Vdc Outputs
• 500 Vac Isolation
• -40 to 85 °C Operating Temperature
• Through Hole or SMT Versions
• Five year warranty

PXC-M Series - 3W to 10W - Single Output / Multiple Output

• Industry Standard DIP-24 Package
• 9-36 Vdc, 18-75 Vdc Inputs
• 3.3, 5, 12, 15, 24, ±5, ±12, ±15 Vdc Outputs
• 5 kVAC Isolation (2 x MOPP)
• IEC/EN60601-1, ES60601-1, CE Mark
• Low Off-Load Power Draw
• 2.5µA Leakage Current
