Multilayer Printed Circuit Board (PCB) Manufacturing

PCBpro®

Flexible options to tailor-fit your needs

PCBpro Features

Flexible lead times
Free UPS Ground shipping
Up to 20 layers
Instant online quoting
Production quantities
Panelization options
NRE / Design review

PCBpro Parameters:

The OneQuote form will inform you which service level of PCB that you have configured, but if you keep these parameters in mind during the design stage there should be no surprises or delays in quoting.

Parameter	Details
Layers	0-20
Thickness	0.020" - 0.135"
Material	FR-4 150Tg, FR-4 170Tg
Engineering Level	Engineering Review (NRE)
Board size	16" x 22" max (352 in 2 per board max)
Soldermask sides	none, 1 or 2
Copper Weight	1, 2 or 3 oz finished
Inspection	Standard IPC-A-600 class 2 or 3, IPC-6012 class 2 or 3
Solder mask Color	Green, Blue, Black, Red, White or Clear
Min. Trace	0.004" (1 oz copper)
Smallest Drilled hole	0.008"
Silk Screen Sides	0, 1 or 2
Min. Space	0.004" (1 oz copper)
Electrical Test	Yes
Silk Screen color	White, Black or Yellow
Routing Options	Individual, Tab, Tab w/ perf, V-Score
Lead time options	2 day to 15 day
Surface Finish	Immersion Silver, Tin Lead (HASL), ENIG, Hard Gold
Slots	Yes
Design Review Option	Yes
UL marking	Yes
Cutouts	Yes
Plated Edges	Yes
Lot code marking	Yes
ITAR	Yes
Controlled Impedance	No
Date code marking	Yes
Via fill	Yes (solder mask filled)
Custom Stack up	Yes
Serialization	No
Counter Sinks	Yes
Counter bore	Yes
Controlled depth milling	No
Gold Fingers	Yes
Blind / buried vias	No
First Article Inspection	Yes
