High quality customized multilayer boards Panel together for Industrial Control

Basic Info Model No.: PCB-A53,is a fusion of multiple meticulously crafted boards, tailored to meet your industrial control needs with utmost precision and quality.

Key Highlights:

  • High-Quality Construction: Our multilayer boards are manufactured to the highest standards, ensuring exceptional durability and reliability for industrial applications.
  • Customized to Your Specifications: We understand that one size does not fit all. That’s why we offer customization to meet your exact requirements, whether it’s the board dimensions, layer count, or other specifications.
  • Seamless Panel Design: Multiple layers are expertly panelized, creating a unified and robust PCB solution, designed to handle the demands of industrial control systems.
  • ENIG Surface: The boards are finished with a premium gold plating, ensuring excellent conductivity and corrosion resistance, while adding a touch of sophistication.

When it comes to industrial control, our multilayer board panels are a testament to exceptional manufacturing capabilities, delivering high-quality, tailor-made solutions for your specific needs.

  • Product Layer: 6L
  • Finished board thickness: 2.0mm
  • Material: FR4
  • PCB Dimensions: 300*340mm
  • Finished copper thickness: 2.0oz
  • Solder mask Color: Green
  • Surface Finished: ENIG 2u

Product Detail

Basic Info
AttributeDetail
Model No.PCB-A53
Dimension300mm*340mm
Surface FinishedENIG 2U
CertificationUL, ISO9001&14001, SGS, RoHS, Ts16949
DefinitionsIPC Class2
Minimum Space/Line0.075mm/3mil
ApplicationVehicle Tracking
OriginMade in China
Production Capacity720,000 M2/Year
Product Description
ITEMCAPABILITYITEMCAPABILITY
Layers1-20LThicker Copper1-6OZ
Products TypeHF(High-frequency) &(Radio Frequency)board, Imedance controlled board, HDIboard, BGA & Fine Pitch boardSolder MaskNanya & Taiyo; LRI & Matt Red. green,yellow, white, blue, black
Base materialFR4(Shengyi China,ITEQ, KB A+,HZ),HITG,FrO6,Rogers,Taconic,Argon,Nalco lsola and so onFinished SurfaceConventional HASL,Lead-free HASL,FlashGold,ENIG (lmmersion Gold) OSP (Entek),lmmersion TiN, lmmersion Silver,Hard Gold
Selective Surface treatmentENIG(immersion Gold) + OSP ,ENIG(immersion Gold) + Gold Finger, Flash Gold Finger, immersionSlive + Gold Finger, Immersion Tin + Gold FingerTechnical SpecificationMinimum line width/gap: 3.5/4mil (laser dril) Minimum hole size: 0.15 mm(mechanical drill/4 mill laser drill) Minimum Annular Ring: 4mil Max Copper thickness: 6Oz Max Production size: 600x1200mm Board Thickness: D/S: 0.2-70mm,Mulltilayers: 0.40-7.Omm Min Solder Mask Bridge: ≥0.08mm Aspect ratio: 15:1 Plugging vias capability: 0.2-0.8mm
TolerancePlated holes Tolerance : ±0.08mm(min±0.05) Non-plated hole tolerance: ±O.05min(min+O/-005mm or +0.05/Omm) Outline Tolerance: ±0.15min(min±0.10mm)Functional test:lnsulating resistance: 50 ohms (normality) Peel off strength: 14N/mm Thermal Stress test: 265C.20 seconds Solder mask hardness: 6H E-test voltage: 50ov±15/-0V 3os Warp and Twist: 0.7%( semiconductor test board 0.3%)
Q/T Lead Time
CategoryQuickest Lead TimeNormal Lead Time
Double-sided24hrs120hrs
4 Layers48hrs172hrs
6 Layers72hrs192hrs
8 Layers96hrs212hrs
10 Layers120hrs268hrs
12 Layers120hrs280hrs
14 Layers144hrs292hrs
16-20 LayersDepends on the specific requirements
Above 20 LayersDepends on the specific requirements
Quality Control

The pass rate of incoming material above 99.9%, the number of mass rejection rates below 0.01%. ABIS certified facilities control all key processes to eliminate all potential issues before producing. ABIS utilizes advanced software to per
