20 kW High Voltage On-board Charger (eOBC20.0HV-01)

In Stock

This product is not available for online purchase.

Please email us to place an order.

Something extra about the product goes here

• Level II Charging 20.0kW
• Full Output Power with Single Phase Input Power
• Highly Efficient
• CAN Controlled
• Compact Design
• Liquid Cooled
• Meets Conventional Truck & Bus Requirements
• Standard SAE J1772 Protocol

Documents and Digital Files

Download Brochure

Please log in to access technical files.

Terms and Conditions of Sale

CSI Terms and Conditions of Sale:Read Here

Product details

General specs

• Model #:eOBC20.0HV-01
• Rated Power:19.2KW Output
• Input Voltage Range:90-264 VAC, 45-65 Hz
• Control Voltage:12V
• Control Current:4.0A
• Output Voltage Range:470-850 VDC
• Output Current:33.0A
• Cooling:Liquid Cooled Water Glycol - 10 lpm
• Working Ambient Temperature:-40°C ~ +60°C
• Environmental Protection:IP67
• Weight: 44 lbs (19.96 kg)
• Dimensions: L: 14.6" × W: 9.8" × H: 6.7" (L: 371mm × W: 249mm × H: 170mm)
