Online Exporter Manual 94v0 Fr4 Pcb Assembly - 2 Layer Printed Circuit Board ENIG Surface Finishing – KingSong

Welcome to KingSong PCB Technology.

Related Services,such as:2 Layer PCB Cost,2 Layer PCB Board,2 Layer PCB Layout,2 Layer PCB Manufacturers etc.

No.	Item	Mass Production	Prototype
1	Layers	1-8 Layers	1-20 Layers
2	Max. Panel Size	600770mm( 23.62″30.31″)	5001200mm(19.69″47.24″)
3	Max.Board Thickness	8.5mm	8.5mm
4	Min. Board Thickness	2L:0.3mm, 4L:0.4mm, 6L:0.8mm	2L:0.2mm, 4L:0.4mm. 6L:0.6mm
5	Min Inner Layer Clearance	0.1mm(4mil)	0.1mm(4mil)
6	Min Line width	0.1mm(4/4 mil)	0.075mm(3/3 mil)
7	Min Line space	0.1mm(4/4 mil)	0.075mm(3/3 mil)
8	Min.Hole Size	0.15mm(8mil)	0.1mm(6mil)
9	Min plated hole thickness	20um(0.8mil)	20um(0.8mil)
10	Min Blind/Buried hole size	0.2mm(8mil)	0.2mm(1-8layers)(8mil)
11	PTH Dia. Tolerance	±0.076mm(±3mil)	±0.076mm(±3mil)
12	Non PTH Dia. Tolerance	±0.05mm(±2mil)	±0.05mm(±2mil)
13	Hole Position Deviation	±0.05mm(±2mil)	±0.05mm(±2mil)
14	Heavy Coppe	4oz/140μm	6oz/175μm
15	Min S/M Pitch	0.1mm (4mil)	0.1mm (4mil)
16	Soldermask colour	Green,black,Blue,White,Yellow,Red	Green,black,Blue,White,Yellow,Red
17	Silkscreen colour	White,Yellow,Red,Black	White,Yellow,Red,Black
18	Outline	Routing,V-Groove, Beveling punch	Routing,V-Groove, Beveling punch
19	Outline Tolerance	±0.15mm ±6mil	±0.15mm (±6mil)
20	Peelable mask	Top,bottom,double sided	Top,bottom,double sided
21	Controlled Impedance	+/- 10%	+/- 7%
22	Insulation Resistance	1×1012Ω(Normal)	1×1012Ω(Normal)
23	Through Hole Resistance	<300Ω(Normal)	<300Ω(Normal)
24	Thermal Shock	3×10sec@288℃	3×10sec@288℃
25	Warp and Twist	≤0.7%	≤0.7%
26	Electric Strength	>1.3KV/mm	>1.4KV/mm
27	Peel Strength	1.4N/mm	1.4N/mm
28	Solder Mask Abrasion	>6H	>6H
29	Flammability	94V-0	94V-0
30	Test Voltage	50-330V	50-330V

(if you need urgent service,we also can meet)

Description	Double Layer	4 Layer	6 Layer	8 Layer	10 Layer or above
Sample(WD)	4	7	8	10	12
Mass production(WD)	7-9	10-12	13-15	16	20

Inner vacuum packing,Outer standard carton box packing.

A:By DHL,UPS,Fedex,TNT etc.

B:By sea for mass quantity according to customer’s requirement.

A:Quote quantity,

B:Gerber file in 274-x format,

C:Technical requirement or parameters(material,layer,copper thickness, board thickness,surface finishing,solder mask/silkscreen color…)

Pls contact us freely to send inquiry,thanks for your support in advance!
