Silicon Carbide (SiC) Devices

This document lists various Silicon Carbide (SiC) devices available in the JLCPCB assembly parts library, including diodes and MOSFETs from multiple manufacturers.

SiC Diodes

Part CodeDescriptionManufacturerStockPrice (1+)Full Reel QtyFull Reel Price
C127908Extended-40℃~+175℃ 1.9V@4A 14A 4A 50uA@600V 600V TO-252(DPAK) SiC Diodes ROHSSTMicroelectronics1$1.29772500$1.38
C157409Extended-40℃~+175℃ 1.2kV 1.5V@2A 12uA@1200V 2A TO-220AC SiC Diodes ROHSSTMicroelectronics6$1.637650$1.71
C176898Extended-55℃~+175℃ 1.8V@10A 100uA@650V 30A 650V 90A ITO-220AC SiC Diodes ROHSKIA Semicon Tech25$2.293550$3.03
C185063Extended 1.35V@20A 20A 4uA@600V 650V Independent TO-247-3 SiC Diodes ROHSROHM Semicon2$10.447930$13.31
C191032Extended-40℃~+175℃ 1 Independent 1.75V@4A 38A 40uA@650V 4A 650V TO-252(DPAK) SiC Diodes ROHSSTMicroelectronics10$1.5561N/A$9.34 (Min:6)
C192070Extended-40℃~+175℃ 1.45V@8A 105uA@650V 200A 650V 8A TO-220AC SiC Diodes ROHSSTMicroelectronics2$2.463550$3.23
C377927Extended 1.56V@10A 10A 650V 9uA@650V Independent TO-220AC SiC Diodes ROHSSTMicroelectronics580$2.074450$2.62
C464168Extended-55℃~+175℃ 1.75V@10A 15A 200uA@650V 650V 760A TO-220-2 SiC Diodes ROHSonsemi139$1.994950$2.18
C467465Extended-55℃~+175℃ 1.2kV 1.75V@15A 125A 200uA@1200V TO-247-3 SiC Diodes ROHSonsemi4$17.2855450$17.82
C472624Extended-40℃~+175℃ 1.75V@6A 60A 60uA@650V 650V 6A TO-220AC SiC Diodes ROHSSTMicroelectronics361$0.873650$1.04
C515400Extended-55℃~+175℃ 1.45V@6A 22A 45A 50nA@650V 650V TO-220-2 SiC Diodes ROHSBASiC Semiconductor3$1.407350$1.87
C515403Extended-55℃~+175℃ 1.43V@10A 30A 650V 70A 70nA@650V TO-220-2 SiC Diodes ROHSBASiC Semiconductor2$2.110950$2.79
C515411Extended-55℃~+175℃ 1.45V@8A 21A 50nA@650V 56A 650V TO-252 SiC Diodes ROHSBASiC Semiconductor2$2.93362500$4.65
C515416Extended 1.43V@10A 32A 650V 70uA@650V Independent TO-263-2L SiC Diodes ROHSBASiC Semiconductor1$2.447650$3.13
C515418Extended 1.2kV 1.47V@10A 35A 4.5uA@1.2kV Independent TO-220-2L SiC Diodes ROHSBASiC Semiconductor1$6.886950$9.26
C533135Extended 1.5V@12A 12A 2uA@650V 650V Independent TO-263-2 SiC Diodes ROHSInfineon Technologies7$7.47141000$7.47
C535845Extended-55℃~+175℃ 1.25V@8A 24A 47A 650V 800nA@420V Independent - SiC Diodes ROHSInfineon Technologies20$1.95841700$2.07
C535846Extended-55℃~+175℃ 1.35V@10A 10A 33uA@420V 55A 650V Independent - SiC Diodes ROHSInfineon Technologies50$2.66201700$2.83

Silicon Carbide Field Effect Transistors (MOSFETs)

Part CodeDescriptionManufacturerStockPrice (1+)Full Reel QtyFull Reel Price
C191056Extended 103W 156mΩ 16pF 21A 35pF 38nC 460pF 5.6V 650V N-Channel TO-247AC-3 Silicon Carbide Field Effect Transistor (MOSFET) ROHSROHM Semicon40$3.170330$4.05
C191059Extended 1.526nF 104nC 262W 30mΩ 42pF 5.6V 650V 70A 89pF TO-247-3 Silicon Carbide Field Effect Transistor (MOSFET) ROHSROHM Semicon1$29.2708450$30.91
C191060Extended 1.2kV 103W 17A 18pF 208mΩ 398pF 41pF 42nC 5.6V N-Channel TO-247AC-3 Silicon Carbide Field Effect Transistor (MOSFET) ROHSROHM Semicon440$4.093130$5.78
C191378Extended-55℃~+200℃ 1.2kV 12A 150W 22nC 290pF 3.5V 30pF 690mΩ 9pF N-Channel HiP-247 Silicon Carbide Field Effect Transistor (MOSFET) ROHSSTMicroelectronics5$6.829730$8.82
C192132Extended 1.2kV 104mΩ 165W 31A 35pF 5.6V 60nC 75pF 785pF TO-247AC-3 Silicon Carbide Field Effect Transistor (MOSFET) ROHSROHM Semicon395$7.382530$9.45
C472655Extended-55℃~+200℃ 1.23nF 1.2kV 105mΩ 15pF 290W 33A 56pF 5V 63nC HiP-247 Silicon Carbide Field Effect Transistor (MOSFET) ROHSSTMicroelectronics1$23.6720600$24.41
C476131Extended-55℃~+175℃ 1.2kV 1.9nF 115pF 13pF 228W 45mΩ 5.7V 52A 52nC N-Channel TO-247-3 Silicon Carbide Field Effect Transistor (MOSFET) ROHSInfineon Technologies20$10.940230$13.74
