Designing PCBs for high-speed functions is a greater challenge. Designers can make it in high-speed PCB design through governed layer stack-up, controlled impedance routing, and qualitative positioning of parts. This is exemplified by the 6-layer communication module which implements these concepts and thus serves well in networking and embedded systems operation.
The common challenges in high-speed PCB design include cross-talk, signal reflection, and EMI issues.
Signaling interference originates from one or more neighboring traces.
Solution: Insert different level planes for routing forward and return pathways of high-speed signals, as well as increase the distance between traces.
Signals get distorted as a result of the existence of impedance discontinuities.
Solution: Employ controlled impedance traces and provision of cynosure termination resistors.
The emission of electromagnetic energy results from the propagation of signals at a high speed, which causes interference with other parts.
Solution: Mitigate trace length and guide signals through solid ground planes.
To solve the challenges, the key considerations in high-speed PCB design include layer stack-up design, impedance control, ground and power integrity, component placement, and signal routing. The below content and images use the same 6-layer high-speed PCB to reveal these considerations in high-speed PCB design one by one.
The sequence of conductive and dielectric layers in PCB is a layer stack-up configuration. It is important for ensuring reliable power distribution, electromagnetic interference suppression, and signal transmission. For high-frequency PCBs, an appropriate stack-up design will limit cross-talk, provide consistent reference planes, and ease the handling of impedance. The 6-layer stack-up for the example communication module PCB is:
In the 6-layer communication PCB example, Ethernet traces, and USB differential pairs are run on the first layer of the communication module while their return paths run above the second layer ground patch.
Impedance matching tends to maintain the integrity of the signal without distortions and reflections. When densities are larger with high-speed transmission, differential pairs of Ethernet and USB for instance will need specific impedances. To achieve 90Ω (USB) or 100Ω (Ethernet), the following materials are used to create differential pairs of Tx+/Rx-:
The best person to contact for assistance on how to select the correct dielectric material and stack-up properties is your PCB manufacturer. The high-speed and high-frequency PCB manufacturer PCBONLINE offers one-on-one engineering support throughout your project, no worries about your high-speed PCB design by working with PCBONLINE.
In high-speed PCBs, power and ground structures are important for reliable operation. The power distribution planes maintain the required voltage levels and the ground planes provide low impedance for the return of the signals. Here is how to achieve this:
In the 6-layer communication PCB example, a case in point is when the communication module has stitching vias at places of high current and places Layer 2 and Layer 5 for ground and Layer 3 for power (3.3V and 1.8V).
The first stage of PCB design is component placement, which enables signal integrity to be maintained and routing less complex. Proper placement directly impacts the performance and reliability of high-speed PCBs.
In the 6-layer example PCB design, to facilitate proper routing, the communication module integrates the Ethernet PHY with the RJ45 connector and the USB 3.x controller with the USB-C connector.
Signal routing defines the physical routes that voltage or current can follow between different components on the PCB. This is among the critical steps in high-speed PCB design, as the routing decisions influence the performance of the device. Below are what to know about signal routing for high-speed signals, clock signals, and power and ground.
The performance level is influenced by the interconnection of the high-speed signals which is a sensitive task. Differential pair routing and Trace geometry must be properly done. Some restrictions accompany the routing of high-speed signals in the PCB design:
Differential pair routing:
To ensure the signal reaches its destination in the correct order, match the trace lengths.
Maintain signal integrity with the help of symmetrical vias.
Trace geometry:
To reduce signal reflection, 90-degree bends should be avoided, while 45-degree bends can be used.
To minimize electromagnetic interference (EMI), communication should be routed over surfaces with uninterrupted ground planes.
In the communication module PCB example, the Ethernet differential pairs in the communication module are routed using length-matched traces between the PHY and RJ45 with a 100Ω impedance.
The clock signals need to be routed carefully as they are very loud in their reception and can become inaccurate, therefore the following needs to be observed:
Routing power and ground involves maintaining a stable power delivery network (PDN) and ensuring minimal noise.
After the signal routing, the high-speed PCB design still needs validation and simulation.
High-speed signals are guaranteed to retain their intended properties throughout the PCB thanks to signal integrity analysis.
Power integrity analysis identifies voltage ripple and noise issues that can impact circuit performance.
In the high-speed PCB example, the performance of an Ethernet communication module prototype can be measured using USB compliance testing tools and packet generators.
If you have a project plan for high-speed or high-frequency applications, whether you have completed the high-speed PCB design or not, you can work with the one-stop advanced PCB manufacturer PCBONLINE for R&D and turnkey PCB manufacturing.
Founded in 1999, PCBONLINE has two large advanced PCB manufacturing bases, one PCB assembly factory, stable supply chains, and an R&D team.
PCBONLINE pays attention to quality and cost-effectiveness in high-speed PCBs. If you want to get a quote or ask questions, you can send emails to pcb@frankenthalerfoundation.org to get a quote.
All stages of a high-speed PCB design ought to be thoroughly taken care of and executed. In this blog, the 6-layer communication module realizes the high-speed PCB design concepts in networking and embedded systems. If you need high-speed PCBs or PCBA, work with the one-stop PCBA manufacturer PCBONLINE.
