Description

UL2651 2mm Ribbon Cable 20 Pin IDC Connector

The 20 pin 2mm ribbon cable is is widely used in electrical appliances, printer, robotics, PCB board circuits connect, industrial equipment, data/communications equipment, gaming equipment, medical equipment, instrumentation equipment, computer cabling, hard drives, CD driver, Video Project Devices, DVD Players, backlights panel, car LCD panels, LCD TV Panels, LED displays, electronic box cabling, automobiles, digital cameras, etc.

SpecificationDetail
CableUL2651 28AWG cable
Cable PitchPH1.0MM Pitch
Length30cm / 11.8inch.
Total Width20mm / 0.78inch
Colorgrey with red edge
ConnectorIDC Female to Female connector, type-A
Pin Number20 Pin connector
Pin Pitch2mm pitch connector
Materialplastic
Rated Current1Amp
Maximum voltageAC 500V / 1Minute
Insulation1000mΩ
Contact resistance15mΩ
Operating Temperature-40 ° C ~ + 105 ° C
Sample AvailableYes
CertifiedUL, VDE, CSA
ServiceOEM ODM Accepted
Production Process
Application
Our Capacity
What kinds of ribbon cable We Can custom：
  • PH2.54 IDC Cable Series
  • PH2.0 IDC Cable Series
  • PH1.27 DIC Cable Series
  • Red IDC DIP Cable Series
Custom ribbon cable connectors Capacity：
  • UL 2651 certified gray cable 2-64 P: PH 1.27 mm, 1.0 mm, 0.635 mm；
  • IDC Connector Series 6-64P: 2.54 IDC, 2.0 IDC, 1.27 IDC
  • DIP Connector Series 6-64 P: 2.54 DIP, 2.0 DIP
  • IDC Gray Cable: Customize any length specification, sample production
  • Rainbow Flat Cable
More WR-TBL Series 3587 – 5.08 mm Horizontal IDC Plug

691358710002 691358710003 691358710004 691358710005 691358710006 691358710007 691358710008 691358710012

More WR-TBL Series 3597 – 5.08 mm Horizontal IDC Plug with Flanges

691359740002 691359740003 691359740004 691359740005 691359740006 691359740007 691359740008 691359740012

More WR-TBL Series 1031 – 3.50 mm / 101 – 5.00 mm / 2141 – 3.50 mm Horiz. Entry Modular

691103110002 691103110003 691101710002 691101710003 691214110002 691214110003

How to Order

Send us your Customized Request– We Quote for you — Creat our Drawings — Send Sample to you — Mass Production
