20 Layer HDI 4oz Fr4 Electronic Printed Circuit Board

20 Layer HDI 4oz Fr4 Electronic Printed Circuit Board

20 Layer HDI 4oz Fr4 Electronic Printed Circuit Board - PCB Printed Circuit Board on sales from China good quality PCB Printed Circuit Board manufacturer

Product Details

Place of Origin:	Guangdong, China (Mainland)
Brand Name:	PY
Certification:	ISO9001
Model Number:	PCB

Payment & Shipping Terms

Minimum Order Quantity:	1
Price:	1
Packaging Details:	Vacuum packing, high quality carton
Delivery Time:	5-10 work days
Payment Terms:	T/T
Supply Ability:	Ten thousand square meters per month

Description

Color:Green,Red,Black,Yellow,White,Blue Number Of Plies:2-4-6-8-10-12-16-20-22-28 Layer Copper Thickness:1-4oz Base Material:FR-4 ,Rogers , Aluminum ,Hight TG Board Thickness:0.6～1.0～1.2～1.6～2.0～2.5～3.0～3.2mm Surface Finishing:HASL(lead Free) / Immersion Gold /osp / Immersion Tin/Immersion Silver Min. Hole Size:3mil Service:OEM Services Provided,PCB/Components Sourcing/Soldering/Programming/Testing..,One-stop Turnkey Service,One Stop Turnkey Service,PCBA Surface Finishing:HASL,ENIG,OSP,HASL Lead Free,spray Tin Application:Electronics Device,ru 94v0 Pcb Printed Circuit Board,Consumer Electronics,rigid Fpc,mobile Usb Charger

High Light

HDI Electronic Printed Circuit Board

4oz Electronic Printed Circuit Board

Fr4 Electronic Pcb Board

Applications

Communications: Traditional telecommunication equipment, FTTP, VOIP, multimedia services, data networking and IT infrastructure products, wireless infrastructure products, power amplifiers, splitters and combiners, high power transistors, etc.
Computer Peripherals: High end printers, cable modem, wireless routers, IP telephones, consumer and office products, banking system etc.
Consumer: Computers, televisions, cameras, digital video recorders (DVR), handheld products, LED, etc.
Automotive: Passenger safety systems, engine control systems, air bags, traction control products, etc.
High End Computing and Storage: High performance computer and server, mainframe system and storage equipment, memory, etc.
Industry: Power supply, main control panel, monitor, CCTV products,automotive control equipment, industry robot, access control products etc
Medical: Magnetic resonance imaging (MRI), computed tomography (CT), emergency response defibrillation units, patient monitoring, implantable devices, robotic surgery systems, biometrics and diagnostic equipment, etc.
Military: Satellite, radar, airplane, control unit, communication equipment .etc.
Test & Measurement: Power meters, electricity tester, thermal tester, light tester, network tester, gas and oil tester, infrared products, semi-conductor test equipment, DUT and probe cards, wafer inspection systems, etc.

Capability

category	project	Description
Base Material	fr-4 ,PTFE ,Polyimide	Ordinary Tg, medium Tg, high Tg, halogen free, Low Dk, Low loss, high CTI, PTFE
LAYER	Rigid PCB	1-32LAYER
	fpc PCB	0-10LAYER
	Rigid -Flexible PCB	2-18LAYER
Board Thickness	Rigid PCB	0.4-6.0MM
	fpc PCB	0.05-0.36MM
	Rigid -Flexible PCB	0.4-6.0MM
Copper Thickness	inner layer	0.5-8.0 OZ
	outer layer	0.5-8.0 OZ
Surface Finishing	Hasl	0.3-1.0um
	Immersion Gold	0.025-0.1um
	OSP	0.2-0.6um
	Immersion tin	0.8-1.2um
Solder mask color	outer layer	Green,black,white,blue,yellow,red
Character color	outer layer	white ,black, yellow
Min. Line Width	inner layer	0.05/0.05MM
	outer layer	0.05/0.05MM
Min. Line Spacing	inner layer	0.05/0.05MM
	outer layer	0.05/0.05MM
Drill Hole	Max Diling dameter	6.5MM
	Min Diling Diameter	0.1mm
	MinSlot	0.60MM
	Drilig tolerance	PTH:+/-0.075mm NPTH:+/-0.05mm
	Slot tolerance	PTH:+/-0.10mm NPTH:+/-0.05mm
Board Size	Rigid PCB	800*2000MM
	fpc PCB	200*800MM
	Rigid -Flexible PCB	200*500MM
Drill Aspect Ratio	Mechanical hole	12.0:1.0
	blind hole	1.0:1.0
Solder mask bridge	green oil	0.08MM
	white,blue,yellow,red	0.1MM
	black oil	0.12MM
Bow and Twist	Rigid PCB	0.5-0.75%
core thickness	Rigid PCB	0.075MM (excluding copper)
Resin plug hole	hole size	0.2-0.35mm
Carbon oil thickness		10um(min)
V - cut	Rigid PCB	30 45 60 (Tolerance: + / - 5 degrees)
impedance		50-120 ohm Tolerance: + / - 10 %
PP type		Commonly used 1080,2116,7628 ,106

Advantages

PCB factory directly
Comprehensive quality control system
Competitive price
Quick turn delivery time from 24hours.
Certificates (ISO/UL E354810/RoHS)
10 years experience in exporting service
No MOQ/MOV.
High quality. Strict through the AOI(Automated Optical Inspection), QA/QC, flying porbe ,Etesting, etc

Tag

Single Sided PCB Double Sided PCB Multilayer circuit pcb Multilayer HDI circuit pcb fpc-Flexible PCB Rigid -Flexible PCB LED lights PCB PCBA SMT PCB pcb layout and design

Contact Details

Ping You Industrial Co.,Ltd Tel:86--15919758327 Fax:86-755-23501556 Contact Person:Ms. Emma
