High Frequency Thick Copper PCB for IoT Devices

High Frequency PCB - RF PCB Manufacturing

This page details various specialized PCB products for high-frequency and RF applications.

Teflon PCB

Product Name: Teflon PCB

• Material: Teflon laminate material
• Quality standard: IPC6012 Class II or Class III
• Dielectric constant: 2.0 - 3.5
• Layers: 2 layer - 34 layer
• Thickness: 0.1mm - 12mm
• Copper thickness: base copper 0.5oz, finished copper thickness 1oz
• Surface technology: Immersion Gold, ISIG
• Special requirements: high precision of RF line There are requirements for DK and DF of materials
• Application: Microwave high-frequency PCB application

Radar PCB

Product Name: Radar PCB

• Material: Teflon /Ceramic PCB
• Quality standard: IPC-6012
• Dielectric constant: 2.0-16
• Layers: 1 Layer - 70 layer
• Thickness: 0.254mm - 6.0mm
• Copper thickness: H/H-1OZ
• Surface technology: Silver(Can choose Gold or OSP)
• Application: Communication radar PCB, detection radar PCB

Cavity PCB

Product Name: Cavity PCB

• Material: Teflon F4MB
• Quality standard: IPC6012 Class 2
• Dielectric constant: 2.55
• Layers: 2Layers
• Thickness: 1.5mm
• Copper thickness: base copper 0.5oz, finished copper thickness 1oz
• Surface technology: Immersion Silver
• Application:Cavity PCB for power divider

Rogers PCB

Product Name: Rogers Substrate PCB

• Material: rogers PCB material
• Quality standard: IPCB6012 Class2 or Class3 rogers PCB material
• Dielectric constant: 2.2-16 the texture of material:rogers ceramic PCB
• Layers: 1layer - multilayer hybrid PCB
• Thickness: 0.1mm - 12mm
• Copper thickness: 0.5oz - 3oz
• Surface technology: Silver, Gold, OSP
• Application:High frequency rogers microwave PCB

Rogers 5880 PCB

Model: Rogers 5880 PCB

• Material: rogers 5880 substrate
• Layer: 1Layer - 24 layer RT duroid 5880
• Dielectric constant: 2.2 5880
• Thickness: 0.2mm - 4.8mm
• Surface Treatment : Immersion Gold
• Rogers 5880 thickness: Base 0.5OZ,Finished 1OZ
• Special process: Teflon multilayer pcb, Countersink PCB
• Application: microwave, instrument, communication

RO4350B PCB

Model: Rogers RO4350B High Frequency Board

• Material:rogers 4350 material
• Layer:2 layer pcb Rogers 4350
• Dielectric Thickness: 0.254-1.524mm
• Ro4350b dielectric constant:3.48
• Thermal Conductivity:0.69w/m.k
• Copper Thickness:Base 0.5OZ, Finised 1OZ
• Finished Thickness:0.35mm-1.7mm
• Surface Treatment:Immersion Gold/Silver
• Trace / Spacing:4mil/4mil

Rogers 4003 PCB

Material: Rogers 4003 material

• rogers 4003 dielectric constant: 3.38
• Layer: 4003+4450F
• rogers 4003 thickness: 0.508mm(20mil)
• Finished Thickness: 2.0mm Rogers 4003 substrate
• Copper Thickness: 17μm
• Finished Copper Thickness: 1OZ
• SurfaceTreatment: Immersion Gold
• Color:Green /White
• Min Trace / Space:6mil/6mil
• Features: Rogers PCB,tg280 high temperature resistant PCB

High frequency PCB

Product: high frequency PCB

• Material: high frequency PCB materials
• Quality standard: IPC 6012 Class2 high frequency pcb
• dk: 2.0 -1.6
• Layers: 1 Layer pcb - 36 layer pcb
• Thickness: 0.254mm - 12mm
• Copper thickness: base copper 0.5oz / 1oz
• Surface technology: Silver, Gold, OSP
• Special process: mixed material, stepped groove
• Application:High Frequency PCB,microstrip antenna

Microwave PCB

Product: Microwave PCB

• Materials: Telfon, PTFE, ceramic
• Quality standard: IPC 6002 PCB
• DK: 2.0-1.6
• Layer: 1 pcb layer - 36 layers pcb
• Thickness: 0.254mm - 12mm
• Copper Thickness: Ground technology: Silver, Gold, OSP
• Special process: mixed materials, stepped grooves
• Application: micro-optical antenna

Hybrid PCB

Product Name: Hybrid PCB

• Material: Teflon, ceramic + fr4
• Quality standard: IPCB6012 Class2 or Class3 pcb material
• Dielectric constant: 2.2-16 the texture of material: Hybrid pcb, Mixed PCB
• Layers: 2layer - multilayer hybrid PCB
• Thickness: 0.1mm - 12mm
• Copper thickness: 0.5oz - 3oz
• Surface technology: Silver, Gold, OSP
• Application: High-frequency microwave hybrid PCB

Microwave circuit PCB

Product: Microwave circuit PCB

• Material: Telfon, PTFE, Ceramics
• Quality standard: IPC 6012 Class2 PCB
• DK: 2.0 -1.6
• Layers: 1 Layer pcb - 36 layer pcb
• Thickness: 0.254mm - 12mm
• Copper thickness: base copper 0.5oz / 1oz
• Surface technology: Silver, Gold, OSP
• Special process: mixed material, stepped groove
• Application: Microstrip antenna,Radar PCB

Optical module PCB

Model : Optical Module PCB

• Layers :8Layers
• Material : TG170 FR4
• Construction : 2+4+2 HDI PCB
• Finished Thickness：0.8mm
• Copper Thickness : 0.5OZ
• Color : Green/White
• Surface treatment: Electric hard gold
• Special technology: golden finger bevel
• Min Trace / Space：3mil/3mil
• Application : Communication equipment, data centers, high-performance computing (HPC), and artificial intelligence (AI) support high-speed data transmission and computing power demands.

Drone antenna

Product Name: Drone Antenna

• Material: Teflon/Ceramic / FR-4
• Quality standard: IPC-6012
• Dielectric constant: 2.0-16
• Layers: 1 Layer - 34 layer
• Thickness: 0.254mm - 6.0mm
• Copper thickness: H/H-3OZ
• Surface technology: Silver(Can choose Gold or OSP)
• Application: Aerial photography, agricultural crop protection, logistics delivery, surveying and mapping, power line inspection, forest fire monitoring, insect radar detection, emergency rescue operations, and other fields.

RF Circuit PCB

Product: RF PCB

• Material: FR-4, Teflon, PTFE, Ceramic, Hydrocarbon
• Quality standard: IPC Class2, Class3 PCB
• DK: 2.0 -1.6
• Layers: 1-2 Layer, Multilayer PCB
• Thickness: 0.254mm - 12mm
• Copper thickness: 0.5oz - 2oz
• Surface technology: Silver, Gold, OSP
• Features: Strict tolerance control of RF circuits
• Application: Antenna, instrument, Equipment

Antenna PCB

Product Name: Antenna PCB

• Material: Teflon / Ceramic / FR-4
• Quality standard: IPC-6012
• Dielectric constant: 2.0-16
• Layers: 1 Layer - 34 layer
• Thickness: 0.254mm - 6.0mm
• Copper thickness: H/H-3OZ
• Surface technology: Silver(Can choose Gold or OSP)
• Application: GPS Antenna PCB, WiFi Antenna PCB, 5G Antenna PCB
