Climate Meter PCE-VA 20

Order no.: PCE-VA 20 GTIN (EAN): 4250348714657

US$396.00 Price ex. Sales Tax, ex. delivery costs

GTIN (EAN) : 4250348714657 Order no. PCE-VA 20 Available in:1-2 days

Your PCE Instruments Benefits

  • Bilingual Technical Support (EN / ES)
  • Special Promotions
  • Public Service, Military and First Responder Discount
  • 30 Day Return Policy
  • 2 Year Warranty

Accessory

  • Set of 2 x Capture Flow Hoods for PCE-VA 20 US$236.00
  • ISO Calibration Certificate CAL-AM US$243.00
  • Telescoping Pole for PCE-VA 20 US$166.00

Description

Climate Meter PCE-VA 20 Combination anemometer-hygrometer-thermometer for assessing wind, weather, indoor / Outdoor environmental climate conditions

PCE-VA 20 is a climate meter for assessing wind, weather, indoor / outdoor environmental climate conditions as well as for testing heating, ventilation and air conditioning or cooling (HVAC) systems. In addition to measuring air temperature, this climate meter measures dew point temperature, wet-bulb temperature, air flow velocity (i.e., wind speed), volume flow and relative humidity (RH). This climate meter features a 10 cm / 3.9" Ø fan impeller, easy-to-read backlit LCD, and functions such as display hold, average value, maximum value, minimum value, battery-saving automatic power off, low-battery indicator, and metric or imperial unit selection.

Highlights

  • Measures air flow velocity, volume flow, relative humidity, air temperature, dew point temperature and wet-bulb temperature
  • Air flow velocity range: 0.2 ... 30 m/s (39.4 ... 5905.5 fpm)
  • Accuracy: ±(1.5% of measured value + 0.3 m/s) when less than 20 m/s, ±(3% of measured value + 0.3 m/s) when more than 20 m/s
  • Resolution: 0.1
  • 10 cm / 3.9" Ø fan impeller
  • Easy-to-read backlit LCD
  • Display hold, average value, maximum value, minimum value, battery-saving automatic power off, low-battery indicator, and metric or imperial unit selection functions

Specification

Technical Specification
ParameterSpecification
Air flow velocity measuring range0.2 ... 30 m/s (39.4 ... 5905.5 fpm)
Air flow velocity accuracy<20 m/s: ±(1.5% of rdg. + 0.3 m/s) >20 m/s: ±(3% of rdg. + 0.3 m/s)
Air temperature measuring range-20 ... 60 °C / -4 ... 140 °F
Air temperature accuracy±0.6 °C
Air temperature resolution0.1 °C / °F
Humidity measuring range0.1 ... 99.9 % r.H.
Humidity accuracy±3 % r.H. (at 25 °C / 77 °F and 10...90 % r.H.) else: ±5 % r.H.
Humidity resolution0.1 % r.H.
Temperature response time60 seconds
Humidity response time60 seconds
LCD update1 x per second
Wet bulb temperature display-20 ... +59.9 °C / -4 ... 139.8°F
Dew point temperature display-5 ... +59.9 °C / 23 ... 139.8°F
Volume flow display0 ... 99999 m³/min
Volume flow resolution0.1 m³/min (0...9999,9 m³/min) 1 m³/min (10000...99999 m³/min)
Automatic shutdownafter 20 minutes of inactivity
LCD size32.5 x 54 mm / 1.28 x 2.13" (H x W)
Power supply4 x 1.5 V AAA batteries
Operating conditions0 ... +50 °C / 32 ... 89.6°F, <80 % r.H.
Storage conditions-10 ... +50 °C / 14 ... 89.6°F, <90 % r.H.
Dimensions269 x 106 x 51 mm / 10.6 x 4.1 x 2.0"
Weightca. 200 g / 7 oz

Delivery Scope

  • 1 x Climate Meter PCE-VA 20
  • 4 x AAA batteries
  • 1 x User manual
  • 1 x Carrying case

Downloads

Manual Datasheet
