Rogers Board is a type of high-performance printed circuit board (PCB) that is manufactured by Rogers Corporation, a global materials technology company. Rogers Boards are known for their high-frequency and high-speed capabilities, as well as their excellent thermal and electrical stability.
The PCB-A16 is a high-quality Rogers Board that has been designed to meet the rigorous demands of high-speed and high-frequency applications. With a model number of PCB-A16, this circuit board features a two-layer design and measures 165mm by 120mm in dimension.
The PCB-A16 is made from high-quality Rogers base material, a specialized laminate material that offers exceptional thermal and electrical stability. With a board thickness of 2.0mm and a copper thickness of 1.0oz, this circuit board is capable of handling high-speed and high-frequency signals with minimal signal distortion. It also features a surface finish of ENIG 2U’’(min) Filled Vias, which helps to ensure consistent and reliable signal transmission.
This circuit board meets IPC Class2 standards, which ensures that it is manufactured to the highest industry standards for quality and reliability. It has a minimum space/line of 0.075mm/3mil, making it ideal for applications that require high precision and accuracy.
The PCB-A16 comes with a green solder mask color and has no legend color. It is vacuum packed for transportation and comes with certifications such as UL, ISO9001&14001, SGS, RoHS, and Ts16949, ensuring that it meets or exceeds all relevant industry standards. This circuit board is made in China and has a production capacity of 720,000 M2/year.
In summary, the PCB-A16 is an exceptional Rogers 2 Layers High Frequency High Speed Circuit Board that offers exceptional performance, reliability, and signal quality. It is the ideal choice for any application that requires high-speed and high-frequency signal transmission with high precision and accuracy.
Quality control processes are implemented to ensure product reliability and adherence to IPC Class standards.
The product holds certifications including UL, ISO9001&14001, SGS, RoHS, and Ts16949.
